| . . | 24100J11093F1 | [1] | HYDR LINES, UPP | |
| 1. | 2418P20108 | [1] | TUBE | |
| 2. | 2418P20107 | [1] | TUBE | |
| 3. | 2418P19995 | [1] | TUBE | TUBE |
| 4. | 2418P19992 | [1] | TUBE | |
| 5. | 2418P19991 | [1] | RIGID TUBE | KOB |
| 6. | 2418P19990 | [1] | RIGID TUBE | KOB |
| 7. | 2444Z3216D1 | [1] | FLEXIBLE HOSE | KOB |
| 8. | 2444Z3217D1 | [1] | FLEXIBLE HOSE | KOB |
| 9. | 2420T2948D6 | [1] | U-BOLT | KOBM08x1.25x ID 64 x 100mm Long |
| 10. | 2432T3970 | [3] | CLAMP | KOB |
| 11. | ZS13C12110 | [1] | SCREW | KOBM12x1.75x110mm Superseded by part number: ZS18C12110 |
| 12. | ZS13C12060 | [1] | SCREW | KOBM12x1.75x60mm Superseded by part number: ZS18C12060 |
| 13. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm YS0201, LS0201 to YS0258, LS0249 |
| . . | ZS13C12035 | [4] | CAPSCREW | KOBSCREW M12x1.75x35mm YS0259, Start Serial: LS0250 Superseded by part number: ZS18C12035 |
| 14. | ZS13C12030 | [2] | CAPSCREW | KOBSCREW M12x1.75x30mm Superseded by part number: ZS18C12030 |
| 15. | ZS23C14045 | [8] | SCREW,Hex Socket Head, M14 x 45mm | KOBM14x2.0x45mm Superseded by part number: ZS28C14045 |
| 16. | ZS18C12040 | [16] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm YS0201, LS0201 to YS0258, LS0249 |
| . . | ZS13C12040 | [16] | SCREW | KOBM12x1.75x40mm YS0259, Start Serial: LS0250 Superseded by part number: ZS18C12040 |
| 17. | ZN13C12010 | [3] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 18. | ZN13C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 19. | ZW22X12000 | [7] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 20. | 2436R393S4 | [2] | VALVE | KOB |
| 21. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 22. | ZW22K14000 | [8] | LOCK WASHER | KOBID 14.2 x OD 21.8 x Th 3.5mm |
| 23. | ZW22K12000 | [20] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 24. | ZW11X08000 | [2] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 25. | ZE13X20001 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) Superseded by part number: ZE13X20000 |
| 26. | ZE13X16000 | [8] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 27. | ZG15F06400 | [5] | COUPLING | KOBYS0201, LS0201 to YS0399, LS0398 |
| . . | R44P0089D15 | [5] | COUPLING | KOBYS0400, Start Serial: LS0398 Superseded by part number: ZG15F06400 |
| 27-2. | R44P0089D15S3 | [5] | GASKET | KOB |
| 28. | R44P0089D8 | [2] | ELASTIC JOINT,101mm ID x 148.8mm OD x 165.1mm L | KOB |
| 28-2. | R44P0089D8S3 | [2] | GASKET | KOB |
| 29. | 2432Z467 | [2] | CLAMP | KOB |
| 30. | 2405Z158 | [2] | BUSHING | KOB |
| 31. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.40 ± 0.65 x OD 80mm |
| 32. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 33. | ZD12P03400 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 34. | ZW11X12000 | [3] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 35. | 2420N379 | [1] | RIGID TUBE | KOB |
| 36. | 2416T21615 | [1] | BRACKET | |
| 37. | 2444T2629D1 | [1] | FLEXIBLE HOSE | KOB |
| 38. | ZX21M12072 | [1] | HOSE | KOB720mm Long (28-11/32 in) Superseded by part number: ZX21M12074 |
| 39. | ZS23C16040 | [4] | CAPSCREW,Hex Socket Head, M16 x 40mm | KOBSCREW M16x2.0x40mm |
| 40. | ZS13C10030 | [2] | SCREW | KOBM10x1.50x30mm Superseded by part number: ZS18C10030 |
| 41. | ZW22K16000 | [4] | LOCK WASHER | KOBID 16 x OD 24 x Th 3.5mm |
| 42. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 43. | ZW11X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 44. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 45. | ZH22X12000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) YS0201, LS0201 to YS0263, LS0242 |
| . . | ZH52F12000 | [1] | TEE YS0284, Start Serial: LS0243 | TEE YS0284, Start Serial: LS0243 |
| 46. | ZD11G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOBID 84.40 ± 0.61 x OD 90mm |
| 47. | 2432T2128D3 | [4] | CLAMP | KOB |
| 48. | 2416T22435 | [1] | SUPPORT | SUPPORT |
| 49. | ZS13C12045 | [2] | SCREW | KOBM12x1.75x45mm Superseded by part number: ZS18C12045 |
| 51. | 2432T4264 | [2] | CLAMP | KOBCLAMP |
| 52. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
