神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (074-01-1) - MOTOR INSTAL, SWING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
535 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN32W00017F1 | [1] | MOTOR-PUMP | KOBInstal, Swing Superseded by part number: ZE91T12000, YN32W01122D1, YN32W01114D1, YN32W01101D1, ZS13C20055, YN64H01391D1, YN32W01075D1, YN15V00069F1 |
| 1. | ZS13C20055 | [13] | SCREW | KOBCap |
| 2. | PV02B01073D3 | [2] | CAP | KOB, Serial Range: YQ11-06001-YQ11-06156 Superseded by part number: YN64H01391D1 |
| 3. | YN32W01101D1 | [1] | LEVEL GAUGE | SM |
| . . | YN64H01391D1 | [2] | CAP | KOB, Start Serial: YQ11-06157 |
| 4. | YN32W01114D1 | [1] | RIGID TUBE | SM |
| 5. | YN32W01075D1 | [1] | RIGID TUBE | SM |
| 6. | ZE91T12000 | [1] | PLUG | SMCap |
| 7-1. | YN15V00035F1 | [1] | HYDRAULIC MOTOR | SMAssy, Hyd Superseded by part number: YN15V00055F1 |
| 7. | YN15V00036F1 | [1] | HYDRAULIC MOTOR | KOBAssy, Swing, Serial Range: YQ11-06001-YQ11-06314 Superseded by part number: YN15V00069F1 |
| . . | YN15V00036F2 | [1] | MOTOR | KOBAssy, Swing, Start Serial: YQ11-06315 Superseded by part number: YN15V00069F1 |
| 7-2. | YN32W00019F1 | [1] | GEAR REDUCTION UNIT | SMAssy, Swing, Serial Range: YQ11-06001-YQ11-06314 Superseded by part number: YN32W00022F2 |
| 7-3. | YN32W00022F1 | [1] | GEAR REDUCTION UNIT | SMAssy, Swing, Start Serial: YQ11-06315 Superseded by part number: YN32W00022F2 |
