神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC025-01-1) - VALVE ASSY, LOCK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
498 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN30V00119F1 | [1] | VALVE | KOBValve Assy, Lock |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCasing |
| 161. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring |
| 164. | NSS | [1] | NOT SOLD SEPARAT | CONO-Ring |
| 166. | NSS | [1] | NOT SOLD SEPARAT | CONO-Ring |
| 167. | NSS | [1] | NOT SOLD SEPARAT | CONO-Ring |
| 171. | ZS23C06035 | [3] | SCREW,Hex Socket Head, M6 x 35mm | KOBCap |
| 201. | NSS | [1] | NOT SOLD SEPARAT | CONPlug |
| 321. | NSS | [1] | NOT SOLD SEPARAT | CONSpring |
| 511. | NSS | [1] | NOT SOLD SEPARAT | CONSpool |
| 541. | NSS | [1] | NOT SOLD SEPARAT | CONSleeve |
