神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC100-01-1) - VALVE ASSY, CONTROL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
296 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN30V00104F1 | [1] | HYDRAULIC VALVE | SMValve Assy, Control |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCase |
| 161. | ZD12G05500 | [1] | O-RING,3.1mm Thk x 54.4mm ID, 90 Duro | KOBO |
| 165. | ZD12P00900 | [1] | O-RING | KOB |
| 201. | YN30V00104S201 | [1] | COVER | SM |
| 206. | NSS | [4] | NOT SOLD SEPARAT | CONPlug |
| 301. | YN30V00104S301 | [1] | SPOOL | SM |
| 321. | YN30V00104S321 | [1] | SPRING | SM |
| 601. | YN35V00050F1 | [1] | SOLENOID VALVE,Cartridge W/Coil | KOBAssy, Solenoid (See HC853) Superseded by part number: YN35V00061F1 |
| 701. | ZS23C10025 | [2] | SCREW,Hex Socket Head, M10 x 25mm | KOBCap Superseded by part number: ZS28C10025 |
| 702. | YX35V00002S171 | [2] | SCREW,Hex Socket Head, M5 x 12mm | KOBCap Superseded by part number: ZS23C05012 |
| 703. | ZS23C12105 | [3] | SCREW,Hex Socket Head, M12 x 105mm | KOBCap |
| 704. | ZS23C12080 | [1] | SCREW,Hex Socket Head, M12 x 80mm | KOBCap |
| 991. | NSS | [1] | NOT SOLD SEPARAT | CONName Plate |
| 992. | NSS | [2] | NOT SOLD SEPARAT | CONPin |
