神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC120-01-1) - VALVE ASSY, CONTROL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
184 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN30V00108F1 | [1] | HYDRAULIC VALVE | SMAssy, Control |
| . . | YN30V00108F2 | [1] | VALVE | KOBAssy, Control |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 111. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 121. | YN30V00108S121 | [1] | PLATE | SM |
| 151. | 2436U1832S651 | [1] | PLUG | KOB |
| 152. | YW30V00001S155 | [1] | PLUG | KOB |
| 153. | 2441U722S490 | [1] | PLUG | KOB |
| 154. | YN30V00108S154 | [1] | PLUG | SM |
| 155. | YW30V00001S156 | [1] | PLUG | KOB |
| 161. | ZD12P01600 | [1] | O-RING | KOB |
| 162. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 163. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 164. | ZD12P01500 | [6] | O-RING | KOB |
| 166. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 167. | ZD12P01400 | [1] | O-RING | KOB |
| 201. | NSS | [2] | NOT SOLD SEPARAT | CONCover |
| 261. | YN30V00108S261 | [2] | O-RING | SM Superseded by part number: ZD12A02100 |
| 271. | YN35V00017S171 | [8] | SCREW,Hex Socket Head, M5 x 16mm | KOBCap Superseded by part number: ZS23C05016 |
| 301. | NSS | [1] | NOT SOLD SEPARAT | CONRod |
| 302. | NSS | [1] | NOT SOLD SEPARAT | CONSpool |
| 322. | EM30V00001S321 | [2] | SPRING | SM |
| 331. | YA30V00002S331 | [2] | SEAL | SMSpring |
| 332. | YA30V00002S332 | [2] | SEAT/SLOT | SMSpring |
| 511. | YA30V00002S511 | [1] | VALVE POPPET | SM |
| 521. | YA30V00002S521 | [1] | SPRING | SM |
| 551. | YA30V00002S551 | [1] | PLUG | SM |
| 601. | YN22V00040F1 | [1] | HYDRAULIC VALVE | SMAssy, Relief (F1 ONLY) |
| 602. | YN22V00041F1 | [2] | HYDRAULIC VALVE | SMAssy, Relief (F1 ONLY) |
| 603. | YN22V00040F2 | [1] | HYDRAULIC VALVE | SMAssy, Relief (F2 ONLY) |
| 604. | YN22V00041F2 | [2] | HYDRAULIC VALVE | SMAssy, Relief (F2 ONLY) |
| 701. | ZS23C12025 | [4] | CAPSCREW,Hex Socket Head, M12 x 52mm | KOBSCREW Cap |
| 702. | ZS23C08080 | [4] | CAP,Hex Socket Head, M8 x 80mm | KOB |
| 901. | NSS | [2] | NOT SOLD SEPARAT | CONName Plate |
| 902. | NSS | [2] | NOT SOLD SEPARAT | CONPin |
