神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC520-49-1) - PUMP ASSY, GEAR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
765 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN10V00031F1 | [1] | HYDRAULIC PUMP | SMPump Assy, Gear |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCover |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONGear, Drive |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONGear, Driven |
| 5. | NSS | [2] | NOT SOLD SEPARAT | CONPlate |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONCover |
| 50. | NSS | [2] | NOT SOLD SEPARAT | CONRing, Back Up |
| 51. | NSS | [2] | NOT SOLD SEPARAT | CONGasket |
| 52. | NSS | [2] | NOT SOLD SEPARAT | CONGasket |
| 55. | YN10V00031S055 | [4] | SCREW | KOBCap |
| 56. | YN10V00019S056 | [4] | WASHER | KOB |
| 57. | NSS | [4] | NOT SOLD SEPARAT | CONBushing |
| 65. | NSS | [1] | NOT SOLD SEPARAT | CONOil Seal |
| 70. | NSS | [1] | NOT SOLD SEPARAT | CONRing, Retaining |
| . . | YN10V00019R100 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 50X2, 51X2, 52X2, 65X1, 70X1 |
