神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC525-01-1) - CASE ASSY, GEAR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
622 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN46W00001F1 | [1] | GEAR | KOBCase Assy, Gear Superseded by part number: YN46W00002F5 |
| . . | YN46W00001F2 | [1] | GEAR | KOBCase Assy, Gear |
| 115. | NSS | [1] | NOT SOLD SEPARAT | CONShaft |
| 117. | NSS | [1] | NOT SOLD SEPARAT | CONGear |
| 118. | NSS | [1] | NOT SOLD SEPARAT | CONGear |
| 125. | NSS | [2] | NOT SOLD SEPARAT | CONBearing, Ball |
| 126. | NSS | [1] | NOT SOLD SEPARAT | CONBearing, Roller |
| 128. | NSS | [2] | NOT SOLD SEPARAT | CONSpacer |
| 262. | NSS | [2] | NOT SOLD SEPARAT | CONCover (F1 ONLY) |
| . . | NSS | [1] | NOT SOLD SEPARAT | CONCover (F2 ONLY) |
| 326. | NSS | [1] | NOT SOLD SEPARAT | CONCase, Gear |
| 414. | ZS23C10020 | [4] | SCREW,Hex Socket Head, M10 x 20mm | KOBCap (F1 ONLY) |
| . . | ZS23C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBCap (F2 ONLY) |
| 435. | YX46W00001S435 | [4] | SOCKET | KOBCapscrew |
| 468. | 2441U436S469 | [1] | PLUG | KOB |
| 710. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOB |
| 711. | ZD12G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOB(F1 ONLY) |
| 728. | ZD12P02400 | [1] | O-RING | KOB |
| 825. | NSS | [1] | NOT SOLD SEPARAT | CONRing |
| 826. | NSS | [1] | NOT SOLD SEPARAT | CONRing |
| 827. | NSS | [1] | NOT SOLD SEPARAT | CONRing |
| 886. | NSS | [2] | NOT SOLD SEPARAT | CONPin |
