| . . | NSS | [1] | NOT SOLD SEPARAT | CONARM ASSY 3.10M |
| . . | YM12B00003F1 | [1] | ARM GROUP (STD) | |
| . . | YM12B00003F2 | [1] | ARM GROUP (N&B) | |
| A1. | YM12B01003F1 | [1] | LINK | KOBLINK, BUCKET |
| A1-1. | YM12B01004P1 | [1] | LINK, BUCKET | |
| A1-2. | YM12B01006P1 | [2] | BUSHING | KOBBUSHING |
| A1-3. | 2405T1885 | [2] | BUSHING | KOBBUSHING |
| A2. | 2406P5564 | [1] | LINK | KOBIDLER (RH),F1 ONLY |
| A3. | 2406P5565 | [1] | LINK | KOBIDLER (LH),F1 ONLY |
| A4. | 2419P3895 | [2] | PIN | KOBPIN Superseded by part number: 2419P4116 |
| A5. | 2419P3896 | [1] | PIN | KOBPIN |
| A6. | YM12B01007P1 | [1] | PIN | KOBPIN |
| A7. | HS18C14115G2 | [1] | BOLT,Hex, M14 x 115mm, Cl 10.9 | KOBM14x2.0x150mm |
| A8. | HS18C14130G1 | [1] | CAPSCREW,M14 x 130mm, Cl 10.9 | KOBSCREW M14x2.0x130mm |
| A9. | ZN18C14011 | [4] | NUT | KOBM14x2.0mm |
| A10. | 2445R138D6 | [4] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| A11. | 2445R138D4 | [2] | SEAL,65mm ID x 80mm OD x 4mm Thk | KOBSEAL, DUST |
| A12. | 2445R138D7 | [2] | SEAL,80mm ID x 95mm OD x 4mm Thk | KOBDust -- ID 80 x OD 95 x Th 4mm |
| A13. | 2445R220D3 | [2] | SEAL,70mm ID x 85mm OD x 5mm Thk | KOBDust -- ID 70 x OD 85 x Th 5mm |
| A14. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A15. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| A16. | B16T0442D88 | [1] | SHIM,100mm OD x 67mm ID x 0.5mm Thk | KOBID 67 x OD 100 x Th 0.5mm |
| A17. | 2418T4037D3 | [1] | SHIM,67mm ID x 110mm OD x 0.9mm Thk | KOBID 67x OD 110 x Th 0.9mm |
| A18. | 2418T4037D2 | [1] | SHIM,67mm ID x 110mm OD x 1.2mm thk | KOBID 67x OD 110 x Th 1.2mm |
| A19. | 2418T4037D5 | [1] | SHIM,67mm ID x 110mm OD x 1.6mm thk | KOBID 67x OD 110 x Th 1.6mm |
| A20. | B16T0442D57 | [2] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| A21. | B16T0442D44 | [2] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| A22. | B16T0442D1 | [2] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| A23. | B16T0442D2 | [2] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| A24. | 2406P5715 | [1] | LINK CONROD | KOBLINK IDLER (RH),F2 only |
| A25. | 2406P5716 | [1] | LINK CONROD | KOBLINK, IDLER (LH),F2 only |
| A26. | 2445R220D18 | [2] | SEAL | KOBDust -- ID 70 x OD 90 x Th 5mm |
| . . | YM12B00038F6 | [1] | ARM | KOBARM ASSY 3.10M |
| B2. | 2405T1888 | [2] | BUSHING | KOBBUHING |
| B3. | 2405T1887 | [2] | BUSHING | KOBBUSHING |
| B4. | YM12B01017P1 | [2] | BUSHING | KOBBUSHING |
| B5. | NSS | [1] | NOT SOLD SEPARAT | CONARM |
| B5-1b. | YM12B01013P1 | [1] | PLATE | KOBPLATE |
| B5-1c. | YN12B01308D1 | [1] | PLATE | KOBPLATE |
| B5-1d. | YN12B01308D2 | [2] | PLATE | KOBPLATE |
| B5-2. | 2418P31360 | [1] | PLATE PLATE | PLATE PLATE |
| B5-3. | 2418P31361 | [1] | PLATE PLATE | PLATE PLATE |
| B5-4. | 2418T27001 | [1] | PLATE | KOBPLATE |
| B5-5. | YN43H01051P1 | [2] | BLOCK | KOBBLOCK TAPPED |
| B5-6. | YM12B01010P1 | [2] | BLOCK, TAPPED | |
| B5-7. | YM12B01012P1 | [2] | BLOCK | KOBBLOCK, TAPPED |
| . . | YM12B00005F1 | [1] | ARM INSTAL | |
| C1. | YM12B01008P1 | [1] | PIN | KOBPIN |
| C2. | YM12B01011P1 | [1] | PIN | KOBPIN Superseded by part number: YB12B01071P1 |
| C3. | 2418T12645D2 | [1] | PLATE | KOB125 x 261 x Th 9.0mm |
| C4. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBM16x2.0x140mm |
| C5. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| C6. | ZN18C16013 | [2] | NUT | KOBM16x2.0mm |
| C7. | B16T0442D52 | [2] | SHIM,82mm ID x 100mm OD x 0.5mm Thk | KOBID 82 x OD 150 x Th 0.5mm |
| C8. | B16T0442D39 | [2] | SHIM,82mm ID x 150mm OD x 0.9mm Thk | KOBID 82 x OD 150 x Th 0.9mm |
| C9. | B16T0442D3 | [1] | SHIM,150mm OD x 82mm ID x 1.2mm Thk | KOBID 82 x OD 150 x Th 1.2mm |
| C10. | B16T0442D4 | [1] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
