神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (08-018) - SOLENOID VALVE ASSEMBLY, P/N YM35V00002F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
118 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM35V00002F1 | [1] | SOLENOID VALVE | KOB |
| 151. | 2441U722S490 | [9] | PLUG | KOB |
| 171. | YX35V00002S171 | [16] | SCREW,Hex Socket Head, M5 x 12mm | KOB Superseded by part number: ZS23C05012 |
| 601. | YN35V00019F1 | [4] | SOLENOID VALVE | KOBPSV-A:Arm Variable Recirulation, PSV-B:By-Pass Cut, PSV-C:Travel Priority, PSV-D:By-Pass Cut |
| 701. | YN35V00020F1 | [3] | SOLENOID VALVE | KOBSV-2:Power Boost, SV-3:Two-Speed Select, SV-4:Operation Lever Lock |
| 702. | YN35V00021F1 | [1] | SOLENOID VALVE | KOBSV-1:Swing Parking Brake |
