神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (08-024) - MANIFOLD ASSY (PILOT VALVE) P/N YN50V00011F1 & YN50V00011F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
737 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN50V00011F1 | [1] | FILTER ASSY | KOBASSY, FILTER, INLINE, QTY-F1: F1 Superseded by part number: YN50V00011F2 |
| . . | YN50V00011F2 | [1] | FILTER | KOBASSY, FILTER, INLINE, QTY-F2: F2 |
| 1. | NA | [1] | NOT SERVICED | FORHEAD, QTY-F1: 1, QTY-F2: 1 |
| 2. | NA | [1] | NOT SERVICED | FORVALVE, CHECK, QTY-F1: 1, QTY-F2: 1 |
| 3. | YN50V01001S005 | [1] | ELEMENT | KOBQTY-F1: 1, QTY-F2: 1 Superseded by part number: 84565888 |
| 4. | YN50V01001S007 | [1] | O-RING,2.5mm Thk x 53mm ID, 90 Duro | KOBQTY-F1: 1, QTY-F2: 1 Superseded by part number: 2446U346S5 |
| 5. | YN50V01001S006 | [1] | BOX | KOBCASE, QTY-F1: 1, QTY-F2: 1 |
| 6. | NA | [1] | NOT SERVICED | FORLABEL, QTY-F1: 1, QTY-F2: 1 |
| 7. | NA | [1] | NOT SERVICED | FORRING, STOP, QTY-F1: -, QTY-F2: 1 |
