| . . | YT30V00008F1 | [1] | PILOT VALVE | KOBQTY-F1: F1 Superseded by part number: YY30V00055F1 |
| . . | YT30V00008F2 | [1] | VALVE | KOBPILOT, QTY-F2: F2 Superseded by part number: YY30V00055F1 |
| 10. | YT30V00008S10 | [1] | SEAT | KOBSPRING, QTY-F1: 2, QTY-F2: 2 Superseded by part number: YT30V00008S010 |
| 11. | YT30V00008S011 | [1] | SPRING | KOBQTY-F1: -, QTY-F2: 2 |
| 12. | YT30V00008S012 | [1] | SPRING | KOBQTY-F1: -, QTY-F2: 2 |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 111. | YT30V00008S111 | [1] | PLATE | KOBQTY-F1: 1, QTY-F2: 1 |
| 121. | 2436U1277S121 | [1] | WASHER | KOBSEAL, QTY-F1: 2, QTY-F2: 2, Remarks: INCL IN KIT |
| 122. | YT30V00008S122 | [1] | O-RING | KOBQTY-F1: 1, QTY-F2: 1 |
| 125. | YT30V00008S125 | [1] | CAPSCREW | KOBSCREW QTY-F1: 2, QTY-F2: 2 |
| 126. | ZP26D05010 | [1] | PIN | KOBRoll -- OD 05 x 10mm Long, QTY-F1: 1, QTY-F2: 1 |
| 131. | YT30V00008S131 | [1] | BUSHING | KOBQTY-F1: 1, QTY-F2: 1 |
| 151. | YT30V00008S151 | [1] | PLATE | KOBQTY-F1: 1, QTY-F2: 1 |
| 201. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL, QTY-F1: 2, QTY-F2: 2 |
| 202. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL, QTY-F1: 2, QTY-F2: 2 |
| 211. | 2436U1277S211 | [1] | PLUG | KOBQTY-F1: 4, QTY-F2: 4 |
| 212. | 2436U1277S212 | [1] | ROD | KOBPUSH, QTY-F1: 4, QTY-F2: 4 |
| 213. | 2436U945S213 | [1] | GASKET | KOBQTY-F1: 4, QTY-F2: 4, Remarks: INCL IN KIT Superseded by part number: 2436U1277S213 |
| 214. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm, QTY-F1: 4, QTY-F2: 4, Included in Kit |
| 216. | YT30V00008S216 | [1] | SEAT | KOBSPRING, QTY-F1: 2, QTY-F2: 2 |
| 217. | 2436U1277S217 | [1] | WASHER | KOBQTY-F1: 4, QTY-F2: 4 |
| 218. | YT30V00008S218 | [1] | SEAT | KOBSPRING, QTY-F1: 2, QTY-F2: 2 |
| 219. | YT30V00008S219 | [1] | SEAT | KOBSPRING, QTY-F1: 2, QTY-F2: 2 |
| 221. | YT30V00008S221 | [1] | SPRING | KOBQTY-F1: 2, QTY-F2: - |
| 222. | YT30V00008S222 | [1] | SPRING | KOBQTY-F1: 2, QTY-F2: - |
| 241. | YT30V00008S241 | [1] | SPRING | KOBQTY-F1: 2, QTY-F2: 2 |
| 242. | YT30V00008S242 | [1] | SPRING | KOBQTY-F1: 2, QTY-F2: 2 |
| 246. | 2436U1277S246 | [1] | SPRING | KOBQTY-F1: 4, QTY-F2: 4 |
| 301. | 2436U2581S301 | [1] | FLEXIBLE JOINT | KOBQTY-F1: 1, QTY-F2: 1 |
| 302. | YT30V00008S302 | [1] | PLATE | KOBQTY-F1: 1, QTY-F2: 1 |
| 312. | YT30V00008S312 | [1] | NUT | KOBQTY-F1: 1, QTY-F2: 1 |
| 501. | YT30V00008S501 | [1] | BOOT | KOBCOVER, QTY-F1: 1, QTY-F2: 1 |
| . . | YT30V00008R100 | [1] | REPAIR KIT | KOBSEAL CONSIST OF ITEM 122X1, 213X4, 214X4, QTY-F2: 1 |
