神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-010) - FILTER ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
673 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2446U180F2 | [1] | SEPARATOR | KOBWATER ASSY |
| 1. | 2446U180S1 | [1] | COVER | KOB |
| 2. | 2446U180S2 | [1] | CASE | KOB |
| 3. | 2446U180S3 | [1] | NUT | KOB |
| 4. | 2446U180S100 | [1] | DRAIN PLUG | KOB |
| 5. | 2446U180S5 | [1] | PLATE | KOB |
| 6. | 2446U180S6 | [1] | FLOAT | KOBLEVELING, WATER |
| 7. | ZD11G06000 | [1] | O-RING,59.40mm ID x 65.60mm OD x 3.10mm | KOBID 59.40 ± 0.61 x OD 65mm |
| 8. | ZD11P01000 | [1] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 9. | 2446U180S9 | [1] | PLATE, CAUTION | PLATE, CAUTION |
| 10. | 2446U180S10 | [2] | SCREW | KOBBOLT |
| 11. | 2446U180S11 | [4] | GASKET | KOB |
| 13. | 2446U180S13 | [1] | CUP | KOBDRAIN |
| 14. | 2446U234S18 | [2] | FLEXIBLE JOINT | KOBSWIVEL |
