神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-009) - FUEL TANK ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
529 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM20P00016F1 | [1] | TANK | KOBAssembly Fuel, Incl A1 - A3 |
| A1. | YM20P00015P1 | [1] | TANK | KOB |
| A2. | YN20P01034P2 | [1] | CAP | KOBFuel Tank Filler |
| A3. | YN50V00017P1 | [1] | STRAINER ASSY. | KOB Superseded by part number: YN50V00029P1 |
| . . | YM20P00017F2 | [1] | TANK INSTAL, FUEL | |
| B1. | ZS13C16040 | [4] | SCREW | KOBM16x2.0x40mm |
| B2. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| B3. | LE33H01017D1 | [3] | SHIM,1.0mm Thk | KOB(1.0) |
| B4. | YF52S00001F1 | [1] | SENSOR | KOBFuel level |
| B5. | 2418T9962 | [1] | PACKING | KOBID 41 x OD 68 x Th 2.0mm |
| B6. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBM05x0.8x12mm |
| B7. | ZW26X05000 | [5] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| B9. | LC25V00001P1 | [1] | COCK | KOB Superseded by part number: LC25V00001P2 |
| B10. | YN20P01135P1 | [1] | HYD CONNECTOR | KOB |
| B11. | YN20P01147P1 | [1] | PACKING | KOB |
