神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-012) - ENGINE CONTROL ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
678 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM11M00004F2 | [1] | CONTROL ASSY, ENG | |
| 1. | YM11M01062P1 | [1] | BRACKET | KOB |
| 2. | YM11M01065P1 | [1] | LEVER | KOB |
| 3. | YN11M01186F1 | [1] | LEVER | KOB |
| 3-1. | YN11M01188P1 | [1] | PLATE | KOB |
| 3-2. | YN11M01190F1 | [1] | LEVER | KOB |
| . . | 2405R312D1215 | [1] | BUSHING | KOB(Part of YN11M01190F1), Not Shown Superseded by part number: 2405R61D2 |
| 3-3. | YN11M01210P1 | [1] | SPRING | KOB |
| 3-4. | ZW16X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 3-5. | ZR16X01200 | [1] | RING | KOBRetaining -- ID 11.1 x OD 12 x Th 1.0mm |
| 4. | YN20S00002F1 | [1] | MOTOR | KOB |
| . . | YN20S00002F1R | [1] | REMAN-ELECTRIC MOTOR | KOBSK160LC-6E ASN YM03U0523 |
| . . | YN20S00002F1C | [1] | CORE-ELECTRIC MOTOR | KOBReturn Number |
| 5. | 2420T8962 | [1] | ROD | KOB |
| 6. | HR37C08000G1 | [1] | BALL JOINT | KOBReplaces 2425R227D2, M08x1.25x45.5mm Long |
| 7. | ZN18C08007 | [3] | NUT | KOBM08x1.25mm |
| 8. | ZM22C10030 | [2] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| 9. | ZW26X10000 | [3] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 11. | 2420R766D3 | [1] | GROMMET | KOB |
| 12. | ZS28C06025 | [1] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 13. | ZW26X06000 | [3] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 14. | ZS18C06025 | [2] | SCREW,Hex, M6 x 25mm | KOBM06x1.0x25mm |
| 15. | YN11M01013D1 | [1] | BALL JOINT | KOBM08x1.25x36mm Long (Left hand thread) Superseded by part number: HR37D08000G1 |
| 16. | 2419R9D1 | [1] | COTTER PIN | KOBOD 06mm x 21.2mm Long |
| 17. | 2420T7359 | [1] | NUT | KOBM08x1.25mm -- Left Hand Threads |
| 18. | YN11M01114P2 | [1] | PIN | KOB Superseded by part number: ZP45X06018 |
| 20. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 21. | ZY26X04009 | [2] | SPACER | KOB |
| 22. | ZS28C10030 | [3] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm |
| 23. | YM11M01063P1 | [1] | CABLE | KOB |
| 24. | YM11M01061P2 | [1] | U-BRACKET | KOB |
| 26. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 27. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 28. | LC11M01034P1 | [1] | ROD | KOB |
| 29. | ZN18C06005 | [1] | NUT | KOBM06x1.0mm |
| 30. | 2420Z1330 | [1] | GROMMET | KOB |
| 31. | 2432T4615 | [1] | LABEL | KOBDecal -- 45x45mm Red triangle |
