神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-013) - POWER TAKE-OFF ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
459 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONPOWER TAKE-OFF ASSY |
| 0. | YM10V00001F3 | [1] | PUMP | KOBASSY, HYD Superseded by part number: YM10V00001F6 |
| 0. | YM10V00001F4 | [1] | PUMP | KOBASSY, HYD Superseded by part number: YM10V00001F6 |
| . . | YM30P00003F1 | [1] | POWER TAKE-OFF ASSY | |
| 1. | YM30P01003P1 | [1] | BRACKET | KOB |
| 2. | YM30P01008F1 | [1] | COUPLING | KOBIncls. Refs. 2-1 - 2-8 |
| 2-1. | YM30P01008S001 | [1] | INSULATING PANEL | KOBPAD, RUBBER |
| 2-2. | YM30P01008S002 | [1] | BEARING ASSY | KOBHUB |
| 2-3. | YM30P01008S003 | [4] | COUPLING | KOBINSERT |
| 2-4. | YM30P01008S004 | [4] | INSERT | KOB |
| 2-5. | YM30P01008S005 | [4] | SCREW | KOB |
| 2-6. | YM30P01008S006 | [4] | SCREW | KOB |
| 2-7. | YM30P01008S007 | [2] | SCREW | KOBSET |
| 2-8. | ZP26D05010 | [4] | PIN | KOBRoll -- OD 05 x 10mm Long |
| 3. | ZS18C10025 | [12] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 4. | ZS23C16045 | [4] | CAP,Hex Socket Head, M16 x 45mm | KOBScrew -- M16x2.0x45mm |
