凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (06-007) - STEERING PUMP, HYDRAULIC GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
727 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN302547
|
[1] |
90 ELBOW
|
BN
9/16-18 x 7/16-20, ZND
|
| 2. |
BN302640
|
[1] |
FITTING
|
BN
4Mor-4Mb
|
| 3. |
BN302650
|
[3] |
FITTING
|
BN
8 MOR-8 MB
|
| 4. |
BN302659
|
[1] |
FITTING
|
BN
20Mor-16Mb
|
| 5. |
BN305057
|
[1] |
FITTING
|
BN
12Mor-10Mb
|
| 6. |
BN324551
|
[1] |
HOSE ASSY.
|
BN
Assembly, 4 X 60"
|
| 7. |
BN313281
|
[1] |
HOSE
|
BN
Assembly, 8 X 65
|
| 8. |
BN317546
|
[1] |
PUMP
|
BN
Gear, LS,1.77, SP, RH
|
| . . |
BN317546R
|
[1] |
REMAN-HYD PUMP
|
BN
FLX3010, FLX3510 BOTH (8/04-8/06)
|
| . . |
BN317546C
|
[1] |
CORE-HYDRAULIC PUMP
|
BN
Return Number
|
| 9. |
342206A1
|
[1] |
HOSE
|
BN
20 x 66
|
| 11. |
BN69793
|
[1] |
GASKET
|
BN
2 Bolt SAE A Pad
|
| 12. |
862-10030
|
[2] |
HEX SOC SCREW,M10 x 30mm, Cl 12.9
|
CAS
Superseded by part number: 87016471
|
| 13. |
86625252
|
[2] |
WASHER,10.8mm ID x 21.5mm OD x 2.5mm Thk
|
FAR
|
| 15. |
410874A1
|
[1] |
PUMP
|
BN
steering valve
|
| . . |
396591A1
|
[1] |
KIT
|
CAS
Seal, Steer Pump Superseded by part number: 87534058
|
