凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (06-008) - STEERING CYLINDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
955 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 0. |
344003A1
|
[1] |
CYLINDER,Double Acting, 25.4mm Rod, 304.8mm Stroke
|
BN
hydraulic, 2.00 x 12 x 1.00
|
| 1. |
86986230
|
[1] |
CASE
|
BN
Assembly
|
| 2. |
BN325749
|
[1] |
SHAFT
|
BN
Assembly
|
| 3. |
86986223
|
[2] |
WEAR RING
|
BN
|
| 4. |
86986216
|
[1] |
SEAL
|
BN
Piston
|
| 5. |
86986226
|
[1] |
PISTON
|
BN
|
| 6. |
14457880
|
[1] |
O-RING,0.103" Thk x 0.987" ID, -120, Cl 5, 75 Duro
|
JES
Superseded by part number: 9672549
|
| 7. |
86986220
|
[1] |
LOCK NUT
|
BN
|
| 8. |
238-5133
|
[2] |
O-RING,0.103" Thk x 1.799" ID, -133, Cl 5, 75 Duro
|
CAS
Superseded by part number: 9820460
|
| 9. |
84251311
|
[1] |
WASHER
|
BN
Backup
|
| 10. |
86986217
|
[1] |
WEAR RING
|
BN
|
| 11. |
86986219
|
[1] |
SEAL
|
BN
Step
|
| 12. |
86986218
|
[1] |
SEAL
|
BN
U-Cup
|
| 13. |
86986215
|
[1] |
WIPER
|
BN
|
| 14. |
86986227
|
[1] |
HEAD
|
BN
|
| 15. |
342216A1
|
[1] |
SEAL KIT
|
BN
|
