神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (10.254.AI) - MUFFLER INSTALL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM12P00010P1 | [1] | MUFFLER | KOB(87345392) Superseded by part number: 87345392 |
| 2. | YM12P01009P1 | [1] | TUBE,64 mm ID x 70 mm OD x 147 mm L | KOBExhaust (72204761) Superseded by part number: 72204761 |
| 3. | YM12P01018P1 | [1] | BRACKET | KOB |
| 4. | YN12P01074P1 | [1] | CLAMP | KOB |
| 5. | YM12P01014P1 | [2] | U-BOLT | KOB |
| 6. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOB |
| 7. | ZN18C10008 | [2] | NUT | KOB |
| 8. | HN18F10000G2 | [8] | NUT | KOB |
| 9. | ZW16X10000 | [2] | WASHER | KOB |
| 10. | 72204524 | [1] | FLEXIBLE HOSE,10mm ID x 800mm L | SM |
| 11. | ZC16X01200 | [1] | CLIP,8mm - 15mm | KOB |
| 12. | YN12P01075P1 | [1] | CLAMP | KOB Superseded by part number: YW12PU1004D1 |
