神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.322.AW[01]) - CONTROL VALVE LINE (MAIN) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
950 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2420R537D090 | [1] | FLEXIBLE HOSE,9.60mm ID x 900mm L | KOB(CNH 72953856) |
| 2. | 2420R537D055 | [1] | HOSE ASSY.,9.60mm ID x 550mm L | KOB(CNH 72953739) |
| 3. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB(CNH 87338415) |
| 4. | 2420R349D110 | [1] | HOSE,1100.00 mm | KOB(CNH 72214739) Superseded by part number: HX21E04110DX |
| 5. | 2420R349D110 | [1] | HOSE,1100.00 mm | KOB(CNH 72214533) Superseded by part number: HX21E04110DX |
| 6. | ZH22X06000 | [4] | HYD CONNECTOR | KOB(CNH 72214523) |
