神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.322.AW[04]) - CONTROL VALVE LINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
558 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN35V00047F2 | [1] | HYDRAULIC VALVE | SM Superseded by part number: YN35V00047F3 |
| 2. | ZH22X04000 | [4] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB(72214744) |
| 3. | ZH32X04000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOB(72214524) |
| 4. | ZH42X06000 | [2] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB(72214541) |
| 5. | 2444Z2891 | [2] | HYD CONNECTOR | KOB(72214521) |
| 6. | HH35X06006G3 | [1] | ELBOW | KOB(72214548) |
| 7. | HH45X06006G2 | [1] | HYD CONNECTOR | SM(87338398) |
| 8. | ZS18C10090 | [1] | SCREW,Hex, M10 x 90mm | KOB(11108034) |
| 9. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOB(11106234) |
| 10. | ZW16H10000 | [2] | WASHER | KOB(14496631) |
