神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.322.AY[01]) - HYD. LINE, REMOTE CONTROL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
467 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LS68H01016D9 | [1] | FLEXIBLE HOSE | SM |
| 2. | LS68H01016D7 | [1] | FLEXIBLE HOSE | SM |
| 3. | LQ68H01032D2 | [1] | FLEXIBLE HOSE | SM |
| 4. | LQ68H01032D1 | [1] | FLEXIBLE HOSE | SM |
| 5. | HX23L06185CR | [1] | FLEXIBLE HOSE | SM |
| 6. | HX23L06190CB | [1] | HYDRAULIC HOSE,9.52 mm ID x 1900.00 mm | KOB |
| 7. | HX23L06185CG | [1] | FLEXIBLE HOSE | SM |
| 8. | HX23L06190CH | [1] | FLEXIBLE HOSE | SM |
| 9. | HX23L06160CH | [1] | FLEXIBLE HOSE | SM(CNH 87707297) |
| 10. | HX23L06160CR | [1] | HOSE,9.53mm ID x 1600mm L | KOB(CNH 87594883) |
| 11. | HX23L06155CB | [1] | FLEXIBLE HOSE | SM |
| 12. | HX23L06160CG | [1] | FLEXIBLE HOSE | SM |
