神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.359.AG[04]) - CONTROL VALVE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
580 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YM30V00013F1 | [1] | CONTROL VALVE | KOB |
| 160. | NSS | [5] | NOT SOLD SEPARAT | CONPLUG |
| 161. | ZD12P02500 | [6] | O-RING | KOBID 24.7mm x OD 28.2mm |
| 162. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 163. | ZD12P01500 | [4] | O-RING | KOB |
| 164. | ZD12P02000 | [18] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 201. | YY30V00058S084 | [3] | COVER ASSY | KOB |
| 203. | YY30V00058S086 | [1] | COVER ASSY | KOB |
| 204. | YY30V00058S087 | [1] | COVER ASSY | KOB |
| 205. | YM30V00008S205 | [7] | GUARD | SM |
| 206. | YM30V00008S206 | [1] | GUARD | SM |
| 209. | YM30V00008S092 | [1] | COVER | SM |
| 211. | YN30V00119F1 | [2] | VALVE | KOBAssembly |
| 216. | YM30V00008S218 | [1] | PISTON | SM |
| 261. | ZD12G04000 | [12] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 264. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 266. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 301. | YM30V00008S301 | [1] | PISTON | SMSPOOL ASSY Superseded by part number: YM30V00008R100 |
| 302. | YM30V00008S302 | [1] | PISTON | SMSPOOL Superseded by part number: YM30V00008R110 |
| 303. | YM30V00008S303 | [1] | PISTON | SM Superseded by part number: YM30V00008R120 |
| 304. | YM30V00008S096 | [1] | PISTON | SMSPOOL |
| 321. | YM30V00008S321 | [3] | SPRING | SM |
| 322. | YM30V00008S322 | [3] | SPRING | SM |
| 331. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOB |
| 336. | YM30V00008S336 | [6] | SEAL RETAINER | SMSTOPPER |
| 511. | 2436U1265S511 | [11] | POPPET | KOB |
| 514. | YW30V00001S514 | [2] | POPPET | KOB |
| 521. | 2436U1265S521 | [11] | SPRING | KOB |
| 523. | YW30V00001S524 | [1] | SPRING | KOB |
| 524. | YW30V00001S524 | [2] | SPRING | KOB |
| 551. | YN30V00021S552 | [12] | PLUG | KOB |
| 556. | YW30V00001S556 | [5] | PLUG | KOB |
| 602. | YN22V00002F1 | [3] | VALVE | KOBAssembly, Overload |
| 603. | YN22V00002F9 | [2] | VALVE | KOBAssembly, Overload |
| 605. | YN22V00029F2 | [1] | HYDRAULIC VALVE | SMAssembly, Overload |
