神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (39.101.AC[01]) - FRAME, ASSY, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
482 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 72200888 | [2] | BUSHING,85mm ID x 118mm OD x 56mm L | SM(YM52F01106P1) Superseded by part number: 84530706 |
| 2. | 72200183 | [1] | COVER | SMCover, NSS, Part of YB52F00093F1 Superseded by part number: 84531174 |
| 3. | 72230471 | [1] | WEAR PAD | SM Superseded by part number: 84531155 |
| 4. | YN53F02521P1 | [1] | FRAME | KOBD rail repair material |
