神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (39.101.AC[02]) - FRAME, ASSY, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
805 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN52F01857P1 | [1] | SEAL | KOB(CNH 87638740) |
| 2. | YN52F01615P1 | [1] | PLATE | SM(CNH 87369423) |
| 3. | ZC16X14800 | [1] | CLIP | KOB(CNH 72955421) |
| 4. | ZS18C10025 | [8] | SCREW,Hex, M10 x 25mm | KOB(CNH 11106234) |
| 5. | YN01F01093P1 | [1] | PLATE | SM |
| 6. | YN52F02334P1 | [1] | GASKET | SM Superseded by part number: 84511193 |
| 7. | YN52F01100D3 | [30] | CAP | KOBScrew (CNH 11125774) |
| 8. | HS53C20105G1 | [1] | CAP | KOBScrew (CNH 87369424) Superseded by part number: 47423235 |
| 9. | ZS18F24130 | [1] | SCREW | KOBCap (CNH 15246234) |
| 10. | ZN18F24019 | [1] | NUT | KOB(CNH 15246234) |
