神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (48.138.AB[03]) - UPPER ROLLER, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
437 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YN64D01068F1 | [4] | ROLLER | KOBAssembly, Incl 1 - 11, Years: -17-DEC-13 Superseded by part number: YN64D01144F1 |
| 1. | 2413N469 | [1] | ROLLER | KOB |
| 2. | YN64D01069P1 | [1] | SHAFT | KOB Superseded by part number: YN64D01144F1 |
| 3. | 2418P21176 | [1] | COLLAR | KOB Superseded by part number: 2418P22958 |
| 4. | YN64D01038P1 | [1] | PLATE | KOB |
| 5. | YN64D01026P1 | [1] | COVER | KOBIncl 12 |
| 6. | 2405T852 | [1] | BUSHING,45mm ID x 50mm OD x 50mm L | KOB |
| 7. | 2445R361F1 | [1] | SEAL,48mm ID x 68.6mm OD x 27mm Thk | KOBIncl 7-1 - 7-2 |
| 7-1. | 2445R361S1 | [1] | SEAL | KOB |
| 7-2. | 2445R361S2 | [1] | O-RING | KOB |
| 8. | ZD11P06500 | [1] | O-RING | KOB |
| 9. | YN64D01016P1 | [2] | BOLT | KOB |
| 10. | YN55V01090P1 | [1] | PLUG | SM |
| 11. | ZR26X07500 | [1] | RING | KOB |
| .. | YN64D01120F1 | [4] | ROLLER | KOBAssembly, Incl 1 - 11 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONRoller |
| 2. | YN64D01125P1 | [1] | SHAFT | SM |
| 3. | YN64D01126P1 | [1] | COLLAR | SM Superseded by part number: YN64D01137P1 |
| 4. | YN64D01127P1 | [1] | PLATE | SM |
| 5. | YN64D01128P1 | [1] | COVER | SM |
| 6. | YN64D01129P1 | [1] | BUSHING | SM |
| 6. | YN64D01130P1 | [1] | BUSHING | SM |
| 7. | YN64D01131P1 | [1] | SEAL | SMFloating |
| 8. | 72956373 | [1] | O-RING | KOB Superseded by part number: ZD11P06500 |
| 9. | 72956322 | [2] | BOLT | KOB Superseded by part number: YN64D01016P1 |
| 10. | 72214631 | [1] | PLUG | IMO Superseded by part number: ZE82T04000 |
| 11. | 72956379 | [1] | RING | KOB Superseded by part number: ZR26X07500 |
