神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (48.138.AB[04]) - UPPER ROLLER, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
807 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | 47640366 | [1] | ROLLER | SMAssembly, Upper, Incl 1 - 11 |
| .. | 47640369 | [1] | KIT | SMRepair Kit, Incl 6, 7, 8, 9, 10, 11 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONRoller |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONShaft |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCollar |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPlate |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONCover |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONBushing |
| 7. | NSS | [2] | NOT SOLD SEPARAT | CONO-ring |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONO-ring |
| 9. | NSS | [2] | NOT SOLD SEPARAT | CONBolt |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONPlug |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONRing |
