神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (50.200.AB[01]) - AIR CONDITIONER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
986 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | R18T0026D13 | [1] | HOSE | KOB |
| 2. | LQ20M00059F1 | [1] | AIR CONDITIONER | SM |
| 3. | YM20M01052P1 | [2] | BRACKET | SM |
| 4. | YN20M01046DN | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 3300.00mm | KOB |
| 5. | ZC16X02400 | [4] | CLIP | KOB |
| 6. | 72273824 | [1] | HEATER HOSE,12.00 mm ID x 1800.00 mm | IMO |
| 7. | 72953308 | [1] | TUBE | IMO Superseded by part number: YN20M01046D9 |
| 8. | PY01P01043D8 | [12] | CABLE TIE,102mm L | KOB |
| 9. | YN20M01094DC | [1] | RIGID TUBE,25mm ID x 30mm OD x 2800mm Length | KOB |
| 10. | LS21P01001D2 | [1] | RIGID TUBE | KOB |
| 11. | PV01P01007P1 | [4] | WASHER | KOB |
| 12. | ZS18C08030 | [4] | SCREW,Hex, M8 x 30mm | KOB |
| 13. | ZM73C10030 | [3] | BOLT,M10x30mm - Course Thread | KOB |
| 14. | LQ20M01327F1 | [1] | CONDENSER | SM |
| 15. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOB |
