神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (50.200.AB[02]) - AIR CONDITIONER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
892 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 72953308 | [1] | TUBE | IMO Superseded by part number: YN20M01046D9 |
| 2. | YM20M01030P1 | [1] | HYD CONNECTOR | KOB |
| 3. | YM20M01052P1 | [2] | BRACKET | SM |
| 4. | YN20M01414D2 | [1] | BELT, TRANSMISSION | KOB |
| 5. | ZC16X02400 | [4] | CLIP | KOB |
| 6. | 72273824 | [1] | HEATER HOSE,12.00 mm ID x 1800.00 mm | IMO |
| 7. | ZM73C06020 | [2] | BOLT,M6x20mm - Course Thread | KOB |
| 8. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOB |
| 9. | YX20M01029F2 | [1] | PULLEY ASSY. | KOB Superseded by part number: YX20M01029F4 |
| 10. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOB |
| 11. | ZW16P10000 | [1] | WASHER | KOB |
| 12. | YM20M01046P1 | [1] | BRACKET | KOB |
| 13. | PY01P01043D8 | [12] | CABLE TIE,102mm L | KOB |
| 14. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOB |
| 15. | ZW16P08000 | [4] | WASHER | KOB |
| 16. | YN20M01094DC | [1] | RIGID TUBE,25mm ID x 30mm OD x 2800mm Length | KOB |
| 17. | EW02E01026D6 | [1] | CLIP | KOB Superseded by part number: 85802889 |
| 18. | 2418Z1333D37 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 2600mm Length | KOB |
| 19. | LS21P01001D2 | [1] | RIGID TUBE | KOB |
| 20. | ZM73C10025 | [2] | BOLT,M10x25mm - Course Thread | KOB |
| 21. | YX91V00001F1 | [1] | AIRCOND. COMPRESSOR,W/ Pulley | KOB |
