神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (50.200.AB[03]) - AIR CONDITIONER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
733 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | R18T0026D13 | [1] | HOSE | KOB |
| 2. | LQ20M01327F1 | [1] | CONDENSER | SM |
| 3. | YX91V00001F1 | [1] | AIRCOND. COMPRESSOR,W/ Pulley | KOB |
| 4. | YN20M01046DN | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 3300.00mm | KOB |
| 5. | LS21P01001D2 | [1] | RIGID TUBE | KOB |
| 6. | 72273824 | [1] | HEATER HOSE,12.00 mm ID x 1800.00 mm | IMO |
| 7. | 72953308 | [1] | TUBE | IMO Superseded by part number: YN20M01046D9 |
| 8. | YN20M01094DC | [1] | RIGID TUBE,25mm ID x 30mm OD x 2800mm Length | KOB |
| 9. | 2418Z1333D37 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 2600mm Length | KOB |
| 10. | YN52S00044P1 | [1] | SENSOR | SM |
| 11. | LQ20M01328P1 | [1] | CONTROL PANEL | SMAir Conditioner |
| 12. | LQ50V01008P1 | [1] | CAB FILTER | SM Superseded by part number: 47814794 |
