神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.910.AC[01]) - BOOM, ATTACHMENT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
643 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM02B01115P1 | [1] | PIN,85mm OD x 812mm L | SM |
| 2. | 15204034 | [1] | SCREW,M20 x 180mm, Cl 10.9 | TOR(ZS18C20180) Superseded by part number: 15204021 |
| 3. | 12163521 | [2] | NUT,M20, Cl 10 | COE(ZN16C20016) Superseded by part number: 9847024 |
| 4. | 72213689 | [2] | SHIM,2mm Thk | SM(YM02B01060P1) Superseded by part number: YM02B01060P1 |
| 5. | 72203140 | [1] | SHIM,0.5mm Thk | NH(B16T0442053) |
| 6. | 72203141 | [1] | SHIM,0.9mm Thk | LEC(B16T0442D40) |
| 7. | 87620687 | [1] | SHIM,94mm ID x 176mm OD x 1.5mm Thk | SM(YN02B01126P1) |
| 8. | 71404856 | [1] | PLUG | TOR(ZE82T06000) |
