神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.912.AA[01]) - ARM, GROUP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
527 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM12B01039P1 | [1] | LINK | KOB |
| 1. | YM12B01041P1 | [1] | LINK | KOBN & B |
| 2. | YM12B01040P1 | [1] | LINK | KOB |
| 2. | YM12B01042P1 | [1] | POWER ARM | KOBN & B |
| 3. | YM12B01052P1 | [2] | PIN,75mm OD x 511mm L | KOBBucket, |
| 3. | YM12B01052P1-U | [2] | Bucket, | PIN |
| 4. | YM12B01068P1 | [1] | PIN,70mm OD x 420mm L | KOBLink to arm attach, |
| 5. | YM12B01070P1 | [1] | PIN,75mm OD x 443mm L | KOBLink to cylinder attach, |
| 6. | HS18C14115G2 | [1] | BOLT,Hex, M14 x 115mm, Cl 10.9 | KOB |
| 7. | HS18C14130G1 | [1] | CAPSCREW,M14 x 130mm, Cl 10.9 | KOB |
| 8. | ZN18C14011 | [4] | NUT | KOB |
| 9. | 2445R220D3 | [4] | SEAL,70mm ID x 85mm OD x 5mm Thk | KOB |
| 10. | 2445R220D4 | [2] | SEAL,78.7mm ID x 95mm OD x 5mm Thk | KOB Superseded by part number: 84499640 |
| 11. | 2445R138D6 | [4] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOB |
| 12. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBStraight |
| 13. | 2418T4037D7 | [1] | SHIM,67mm ID x 110mm OD x 0.5mm Thk | KOB |
| 14. | 2418T4037D3 | [1] | SHIM,67mm ID x 110mm OD x 0.9mm Thk | KOB |
| 15. | 2418T4037D5 | [1] | SHIM,67mm ID x 110mm OD x 1.6mm thk | KOB |
| 16. | YM12B01063D1 | [2] | SHIM,67mm ID x 110mm OD x 2mm Thk | KOB |
| 17. | B16T0442D57 | [2] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOB |
| 18. | B16T0442D44 | [2] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOB |
| 19. | B16T0442D2 | [2] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOB |
| 20. | YN12B01602D1 | [4] | SHIM,72mm ID x 130mm OD x 2mm Thk | KOB |
| 21. | YM12B01147F1 | [1] | LINK | KOBLink, Bucket |
| 22. | 87344334 | [2] | LINK CONROD | SM |
| 22. | 2445R220D2 | [2] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOB Superseded by part number: 84499663 |
