卡特零件查询（735） 183-6195: FUMES DISPOSAL GP
广数供应链运营团队, 15 02月, 2025，浏览：
540 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4N-5264 | [1] | BRACKET AS | |
| | 1F-0750 | [1] | NUT-WELD(3/8-16-THD) | |
| 2. | 4N-6162 | [1] | BRACKET | |
| 3. | 4S-5719 | [1] | SPACER(10.31X25X12.7-MM THK) | |
| 4. | 9M-2904 | [4] | CLAMP-HOSE | |
| 5. | 9Y-5281 | [1] | HOSE | |
| 6. | 123-9711 | [1] | HOSE | |
| 7. | 123-9817 | [1] | TUBE | |
| 8. | 189-9312 | [1] | TUBE | |
| 9. | 0S-0509 | [2] | BOLT(3/8-16X0.75-IN) | |
| 10. | 2S-2053 | [1] | CLIP(LOOP) | |
| 11. | 3B-1915 | [1] | BOLT(3/8-16X1.375-IN) | |
| 12. | 5M-2894 | [4] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 13. | 7L-6326 | [1] | CLIP | |
| 14. | 9S-8752 | [1] | NUT-FULL(3/8-16-THD) | |
