现代零件查询50/60/70D-7A STEERING CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
888 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31FQ-09003
|
[1] |
CYLINDER ASSY
|
|
| 1. |
31Y3-23121
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y3-23160
|
[1] |
ROD ASS'Y
|
|
| K3. |
31YC-99H50
|
[1] |
SEAL-PISTON
|
|
| 4. |
31Y3-19480
|
[2] |
GLAND
|
|
| 5. |
S731-055030
|
[2] |
BUSHING-DU
|
|
| K6. |
Y200-055011
|
[2] |
SEAL-ROD
|
|
| K7. |
Y180-055020
|
[2] |
RING-BACK UP
|
|
| K8. |
Y110-055011
|
[2] |
WIPER-DUST
|
|
| 9. |
Y190-069000
|
[2] |
RING-SNAP
|
|
| K10. |
S632-075004
|
[2] |
O-RING
|
|
| K11. |
S642-075003
|
[2] |
RING-BACK UP
|
|
| K12. |
S632-080004
|
[2] |
O-RING
|
|
| 13. |
31YC-67010
|
[2] |
WASHER-LOCK
|
|
| 14. |
31YC-19020
|
[2] |
BUSH-PIN
|
|
| K. |
31YC-19501
|
[1] |
SEAL KIT
|
|
