神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.AE[01]) - SUN VISOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
477 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YN32T02529F1 | [1] | KIT | KOBDIA, Lights and Rainguard, Incl 1 - 13 and Fig 88.100.AE(02) 1 - 5 Superseded by part number: 87015736, 2420R372D7, 84563611, LC55C01001P1, YN50S00040D4, 12654421, LQ80E01019P2, YN55C01025P1, 16043231, 71450974, LQ55C01027P1, YN24S00010P1, LQ55C01013P1, LQ55C01002F1, LC55C01004P1, 895-11012, YT50C01020P1 |
| 1. | LQ55C01002F1 | [1] | PANEL | SM |
| 2. | LQ55C01027P1 | [1] | WEATHERSTRIP | KOB |
| 3. | 72209106 | [6] | RETAINER | IMO Superseded by part number: YT50C01020P1 |
| 4. | 84151536 | [6] | WASHER | SM Superseded by part number: YN55C01025P1 |
| 5. | 16043034 | [4] | SCREW,M8 x 12mm, Cl 10.9 | LEC Superseded by part number: 16043031 |
| 6. | 12654401 | [6] | WASHER,8.15mm ID x 17mm OD x 3mm Thk | MKT Superseded by part number: 12654421 |
| 7. | 16043231 | [2] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LEC(ZS18C08016 or ZW73C08016) |
| 8. | 14496731 | [8] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 9. | LQ55C01013P1 | [2] | SPACER | SMBetween Ref 12 (Bracket) and Cab |
| 10. | 11112434 | [2] | BOLT,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11112431 |
| 11. | 2420R372D7 | [2] | GROMMET | KOB |
| 12. | LC55C01001P1 | [1] | BRACKET | SM |
| 13. | LC55C01004P1 | [1] | INSULATOR | SM |
