神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.119.AB[04]) - GUARD INSTALL (TOOL BOX) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
612 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YB21C01595F1 | [1] | GUARD | SMAssembly |
| 2. | 11107434 | [4] | SCREW,Hex, M10 x 60mm, Cl 10.9 | LEC Superseded by part number: 11107431 |
| 3. | 72201225 | [13] | WASHER,13mm ID x 30mm OD x 3.2mm Thk | IMO Superseded by part number: 4952483 |
| 4. | 10517074 | [9] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | TTF Superseded by part number: 412123 |
| 5. | 72201210 | [1] | RUBBER BUMPER | IMO Superseded by part number: 84530718 |
| 6. | 12164721 | [1] | NUT,M10 x 1.25, Cl 10 | TTF |
| 7. | YB21C01524P1 | [1] | COVER | SM |
| 8. | 11112234 | [8] | BOLT,Hex, M12 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11112231 |
| 9. | LB21C01398P1 | [3] | RUBBER STRIP,13mm W x 100mm L x 3mm Thk | SM |
| 10. | YB21C01526P1 | [1] | COVER | SM |
| 11. | YM21C01334P1 | [1] | PLATE | SM |
| 12. | 11112434 | [4] | BOLT,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11112431 |
