神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.151.AF[03]) - CAB INTERIOR TRIM, AIR DUCT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1015 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN17M01432F2 | [1] | COVER ASSY | KOBAssembly, IncL Ref 1-13 |
| 1. | YN17M01485P1 | [1] | RIVET | KOB |
| 2. | YN17M01483F2 | [1] | COVER ASSY | KOBAssembly, Inc. 3-6 |
| 3. | YN17M01508P1 | [2] | BUSHING | KOB |
| 7. | YN20M01801F2 | [1] | DUCT | KOBAssembly, Inc. 8-13 |
| 8. | YN20M01802F2 | [1] | DUCT | KOBDuct, NSS, Part of YN20M01801F2 |
| 11. | YN20M01808F2 | [1] | DUCT | KOBAssembly, Inc. 12-13 |
| 14. | YN17M01508P1 | [2] | BUSHING | KOB |
| 15. | YN17M01434F2 | [1] | COVER ASSY | KOBAssembly, Inc. 14 |
| 16. | YN17M01488F1 | [1] | HOLDER | KOBAssembly, Inc. 17-18 |
| 17. | YN17M01489P1 | [1] | HOLDER | KOB |
| 18. | YN17M01508P1 | [2] | BUSHING | KOB |
| 19. | YN17M01492P1 | [1] | RUBBER SLEEVE | KOB Superseded by part number: YN17M01435F2 |
| 20. | YN17M01490F2 | [1] | HOLDER | KOBAssembly, Inc. 21-22 |
| 21. | YN17M01508P1 | [2] | BUSHING | KOB |
| 23. | YN17M01508P1 | [2] | BUSHING | KOB |
| 24. | YN17M01436F2 | [1] | COVER ASSY | KOBAssembly, Inc. 23 |
| 25. | YN17M01508P1 | [2] | BUSHING | KOB |
| 26. | YN17M01438F2 | [1] | COVER ASSY | KOBAssembly, Inc. 25 |
