神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.151.AF[04]) - CAB INTERIOR TRIM, REAR COVER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
941 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN17M01440F2 | [1] | COVER ASSY | KOBInc. 1-3 |
| 1. | YN17M01508P1 | [2] | BUSHING | KOB |
| 2. | YN17M01499P1 | [2] | SEAL | KOB |
| 3. | YN17M01498P2 | [1] | COVER | KOB |
| 4. | YN17M01441F1 | [1] | COVER | SMInc. 5 |
| 5. | YN17M01501P1 | [1] | INSULATION | KOBNSS |
| 6. | YN17M01504F2 | [1] | COVER | KOBAssembly, Inc. 6-8 |
| 7. | YN17M01508P1 | [2] | BUSHING | KOB |
| 9. | YN17M01502F2 | [1] | COVER | KOBAssembly, Inc. 9 -10 |
| 11. | YN17M01507P1 | [1] | SEAL | KOB |
