神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-01-02[02]) - VALVE ASSY, CONTROL (YM30V00011F1) PAGE 2 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
212 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00011F1 | [1] | CONTROL VALVE | KOBAssembly, Incls. Figures (08-01-01) - (08-01-09) Superseded by part number: YM30V00011F2 |
| 102. | NA | [1] | NOT SERVICED | FORBody |
| 154. | YN30V00001S154 | [2] | PLUG | KOB |
| 155. | YW30V00001S155 | [4] | PLUG | KOB1/2" |
| 161. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 163. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 164. | ZD12P01500 | [4] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 567. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 973. | ZS23C14130 | [9] | CAPSCREW,Hex Socket Head, M14 x 130mm | KOBSCREW M14x2.0x130mm |
