神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-01-05[05]) - VALVE ASSY, CONTROL (YM30V00011F1) PAGE 5 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
896 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00011F1 | [1] | CONTROL VALVE | KOBAssembly, Incls. Figures (08-01-01) - (08-01-09) Superseded by part number: YM30V00011F2 |
| 156. | YN30V00001S158 | [1] | PLUG | KOB |
| 161. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 167. | ZD12P00800 | [1] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 201. | YM30V00008S201 | [5] | GUARD | SMCover |
| 205. | YM30V00008S205 | [7] | GUARD | SMCover |
| 209. | YM30V00008S209 | [1] | GUARD | SMCover |
| 211. | YN30V00119F1 | [2] | VALVE | KOBControl |
| 218. | YM30V00008S218 | [1] | PISTON | SM |
| 221. | YM30V00008S221 | [1] | PLUG | SM |
| 261. | 2436U1457S162 | [12] | O-RING,2mm Thk x 39.5mm ID, 90 Duro | KOB |
| 264. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 302. | YM30V00008S302 | [1] | PISTON | SMSpool, Arm1 Superseded by part number: YM30V00008R110 |
| 304. | YM30V00008S304 | [1] | PISTON | SMSpool, Bucket Superseded by part number: YM30V00008R130 |
| 319. | YM30V00008S319 | [2] | SPRING | SM |
| 320. | YM30V00008S320 | [2] | SPRING | SM |
| 321. | YM30V00008S321 | [3] | SPRING | SM |
| 322. | YM30V00008S322 | [3] | SPRING | SM |
| 331. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOB |
| 336. | YM30V00008S336 | [6] | SEAL RETAINER | SMStopper |
| 339. | YM30V00008S339 | [5] | SEAL RETAINER | SMStopper |
| 511. | 2436U1265S511 | [11] | POPPET | KOB |
| 514. | YW30V00001S514 | [2] | POPPET | KOB |
| 521. | 2436U1265S521 | [11] | SPRING | KOB |
| 524. | YW30V00001S524 | [3] | SPRING | KOB |
| 551. | YN30V00021S552 | [12] | PLUG | KOB |
| 556. | YW30V00001S556 | [5] | PLUG | KOB |
| 561. | ZD12P02000 | [18] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 602. | YN22V00002F1 | [3] | VALVE | KOBOverload Relief -- See Figure 08-06 |
| 603. | YN22V00002F9 | [2] | VALVE | KOBRelief -- See Figure 08-26 |
| K. | YM30V00008R110 | [1] | KIT | SMKit, Arm Repair Contains 302x1, 321x1, 322x1, 331x2, 333x1, 336x1 |
| K. | YM30V00008R130 | [1] | KIT | SMKit, Bucket Repair Contains 304x1, 319x1, 320x1, 331x2, 333x1, 339x1 |
