神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-01-06[06]) - VALVE ASSY, CONTROL (YM30V00011F1) PAGE 6 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
879 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00011F1 | [1] | CONTROL VALVE | KOBAssembly, Incls. Figures (08-01-01) - (08-01-09) Superseded by part number: YM30V00011F2 |
| 161. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 162. | ZD12G02500 | [6] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 201. | YM30V00008S201 | [5] | GUARD | SMCover |
| 205. | YM30V00008S205 | [7] | GUARD | SMCover |
| 261. | 2436U1457S162 | [12] | O-RING,2mm Thk x 39.5mm ID, 90 Duro | KOB |
| 264. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 308. | YM30V00008S308 | [1] | PISTON | SMSpool, Arm2 Superseded by part number: YM30V00008R170 |
| 311. | YM30V00008S311 | [1] | PISTON | SMSpool, Option Superseded by part number: YM30V00008R200 |
| 325. | YM30V00008S325 | [6] | SPRING | SM |
| 326. | YM30V00008S326 | [1] | SPRING | SM |
| 329. | YM30V00008S329 | [1] | SPRING | SM |
| 330. | YM30V00008S330 | [1] | SPRING | SM |
| 331. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOB |
| 337. | YM30V00008S337 | [1] | SEAL RETAINER | SMStopper |
| 339. | YM30V00008S339 | [5] | SEAL RETAINER | SMStopper |
| 511. | 2436U1265S511 | [11] | POPPET | KOB |
| 515. | YM30V00008S515 | [1] | POPPET | SM |
| 521. | 2436U1265S521 | [11] | SPRING | KOB |
| 551. | YN30V00021S552 | [12] | PLUG | KOB |
| 561. | ZD12P02000 | [18] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 604. | YN30V01062P1 | [2] | PLUG | SM |
| 606. | YN22V00029F2 | [2] | HYDRAULIC VALVE | SMAssembly, Overload -- See Figure 08-07 |
| K. | YM30V00008R170 | [1] | KIT | SMArm2 Repair Contains 308x1, 325x1, 326x1, 331x2, 333x1, 339x1 |
| K. | YM30V00008R200 | [1] | KIT | SMOption Repair Contains 311x1, 329x1, 330x1, 331x2, 333x1, 337x1 |
