| . . | YM30V00011F1 | [1] | CONTROL VALVE | KOBAssembly, Incls. Figures (08-01-01) - (08-01-09) Superseded by part number: YM30V00011F2 |
| 154. | YN30V00001S154 | [2] | PLUG | KOB |
| 161. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 162. | ZD12G02500 | [6] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 164. | ZD12P01500 | [4] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 166. | ZD12P01000 | [7] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 201. | YM30V00008S201 | [5] | GUARD | SMCover |
| 202. | YM30V00008S202 | [4] | GUARD | SMCover |
| 205. | YM30V00008S205 | [7] | GUARD | SMCover |
| 261. | 2436U1457S162 | [12] | O-RING,2mm Thk x 39.5mm ID, 90 Duro | KOB |
| 264. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 305. | YM30V00008S305 | [1] | PISTON | SMSpool, Boom Confluence Superseded by part number: YM30V00008R140 |
| 306. | YM30V00011S306 | [2] | SPOOL | SMSpool, Travel |
| 310. | YM30V00008S310 | [1] | PISTON | SMSpool, P2 Unload |
| 321. | YM30V00008S321 | [3] | SPRING | SM |
| 322. | YM30V00008S322 | [3] | SPRING | SM |
| 325. | YM30V00008S325 | [6] | SPRING | SM |
| 327. | YM30V00008S327 | [2] | SPRING | SM |
| 328. | YM30V00008S328 | [3] | SPRING | SM |
| 331. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOB |
| 336. | YM30V00008S336 | [6] | SEAL RETAINER | SMStopper |
| 339. | YM30V00008S339 | [5] | SEAL RETAINER | SMStopper |
| 511. | 2436U1265S511 | [11] | POPPET | KOB |
| 521. | 2436U1265S521 | [11] | SPRING | KOB |
| 551. | YN30V00021S552 | [12] | PLUG | KOB |
| 561. | ZD12P02000 | [18] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 567. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 603. | YN22V00002F9 | [2] | VALVE | KOBRelief -- See Figure 08-26 |
| K. | YM30V00008R140 | [1] | KIT | SMBoom Confl. Repair Contains 305x1, 321x1, 322x1, 331x2, 333x1, 336x1 |
| K. | YM30V00011R150 | [1] | SPOOL | KOBKit, Travel Repair Contains 306x1, 325x1, 327x1, 331x2, 333x1, 339x1 |
| K. | YM30V00008R190 | [1] | KIT | SMP2 Unload Repair Contains 310x1, 325x1, 328x1, 331x2, 333x1, 336x1 |
