神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-01-08[08]) - VALVE ASSY, CONTROL (YM30V00011F1) PAGE 8 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
958 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00011F1 | [1] | CONTROL VALVE | KOBAssembly, Incls. Figures (08-01-01) - (08-01-09) Superseded by part number: YM30V00011F2 |
| 161. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 166. | ZD12P01000 | [7] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 203. | YM30V00008S203 | [1] | GUARD | SMCover |
| 204. | YM30V00008S204 | [1] | GUARD | SMCover |
| 205. | YM30V00008S205 | [7] | GUARD | SMCover |
| 206. | YM30V00008S206 | [1] | GUARD | SMCover |
| 211. | YN30V00119F1 | [2] | VALVE | KOBControl |
| 261. | 2436U1457S162 | [12] | O-RING,2mm Thk x 39.5mm ID, 90 Duro | KOB |
| 264. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 266. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 279. | ZS23C06065 | [3] | SCREW,Hex Socket Head, M6 x 65mm | KOBM06x1.0x65mm |
| 301. | YM30V00008S301 | [1] | PISTON | SMSpool, Boom Superseded by part number: YM30V00008R100 |
| 303. | YM30V00008S303 | [1] | PISTON | SMSpool, Swing Superseded by part number: YM30V00008R120 |
| 319. | YM30V00008S319 | [2] | SPRING | SM |
| 320. | YM30V00008S320 | [2] | SPRING | SM |
| 321. | YM30V00008S321 | [3] | SPRING | SM |
| 322. | YM30V00008S322 | [3] | SPRING | SM |
| 331. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOB |
| 336. | YM30V00008S336 | [6] | SEAL RETAINER | SMStopper |
| 339. | YM30V00008S339 | [5] | SEAL RETAINER | SMStopper |
| 511. | 2436U1265S511 | [11] | POPPET | KOB |
| 514. | YW30V00001S514 | [2] | POPPET | KOB |
| 521. | 2436U1265S521 | [11] | SPRING | KOB |
| 524. | YW30V00001S524 | [3] | SPRING | KOB |
| 551. | YN30V00021S552 | [12] | PLUG | KOB |
| 556. | YW30V00001S556 | [5] | PLUG | KOB |
| 561. | ZD12P02000 | [18] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 602. | YN22V00002F1 | [3] | VALVE | KOBOverload Relief -- See Figure 08-06 |
| K. | YM30V00008R100 | [1] | KIT | SMBoom Repair Contains 301x1, 319x1 320x1, 331x2, 333x1, 339x1 |
| K. | YM30V00008R120 | [1] | KIT | SMSwing Repair Contains 303x1, 321x1, 322x1, 331x2, 333x1, 336x1 |
