神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-01-09[09]) - VALVE ASSY, CONTROL (YM30V00011F1) PAGE 9 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
558 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00011F1 | [1] | CONTROL VALVE | KOBAssembly, Incls. Figures (08-01-01) - (08-01-09) Superseded by part number: YM30V00011F2 |
| 153. | YT30V00009S153 | [1] | PLUG | SM |
| 162. | ZD12G02500 | [6] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 166. | ZD12P01000 | [7] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 511. | 2436U1265S511 | [11] | POPPET | KOB |
| 521. | 2436U1265S521 | [11] | SPRING | KOB |
| 551. | YN30V00021S552 | [12] | PLUG | KOB |
| 561. | ZD12P02000 | [18] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 604. | YN30V01062P1 | [2] | PLUG | SM |
| 605. | YN30V00120F2 | [2] | VALVE | KOBControl -- See Figure 08-09 |
