神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-14-01[00]) - HYDRAULIC PUMP ASSEMBLY (YM10V00006F1 & YM10V00006F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
398 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM10V00006F1 | [1] | HYDRAULIC PUMP | SMAssembly Superseded by part number: YM10V00006F2 |
| . . | YM10V00006F2 | [1] | HYDRAULIC PUMP | SMAssembly |
| 1. | YM10V00006S111 | [1] | SHAFT | SM |
| 2. | YM10V00006S113 | [1] | SHAFT | SM |
| 3. | YM10V00006S116 | [1] | GEAR | SM |
| 4. | YM10V00006S123 | [2] | BEARING | SM |
| 5. | YM10V00006S124 | [2] | BEARING | SM |
| 6. | YW10V00003S127 | [2] | SPACER | KOB |
| 7. | YM10V00006S153 | [2] | PLATE | SM |
| 8. | YM10V00006S156 | [2] | BUSHING | SM |
| 9. | 2437U213S157 | [12] | SPRING | KOB |
| 10. | YM10V00006S211 | [2] | PLATE | SM |
| 11. | YM10V00006S251 | [2] | PLATE | SMF1 Only |
| . . | YM10V00006S984 | [2] | PLATE | SMPlate, F2 Only |
| 12. | YM10V00006S255 | [2] | PIN | SMF1 Only |
| . . | YM10V00006S985 | [2] | PIN | SMPin, F2 Only |
| 13. | YM10V00006S256 | [2] | SPRING | SMF1 Only |
| . . | YM10V00006S899 | [2] | RING | SMRing, F2 Only |
| 14. | YM10V00006S261 | [1] | GUARD | SMCover |
| 15. | YM10V00006S263 | [1] | GUARD | SMCover |
| 16. | YM10V00006S271 | [1] | BOX | SMCase Superseded by part number: YM10V00006F2 |
| 17. | YM10V00006S272 | [1] | BOX | SMCase Superseded by part number: YM10V00006F2 |
| 18. | YM10V00006S312 | [1] | BLOCK | SM Superseded by part number: YM10V00006F2 |
| 19. | YM10V00006S401 | [2] | SCREW | SM |
| 20. | YM10V00006S402 | [2] | SCREW | SM |
| 21. | ZS28C06016 | [4] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm |
| 22. | ZS23C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 23. | YW30V00001S155 | [4] | PLUG | KOB1/2" |
| 24. | 2441U722S490 | [9] | PLUG | KOB1/16" NPTF |
| 25. | YM10V00006S532 | [2] | PISTON | SM |
| 26. | YM10V00006S533 | [2] | PLUG | SM |
| 27. | 2437U188S534 | [2] | POPPET | KOB |
| 28. | YM10V00006S535 | [2] | RETAINER | SMStopper |
| 29. | YW10V00003S702 | [2] | O-RING | KOB |
| 30. | YM10V00006S710 | [1] | O-RING | SM |
| 31. | YX10V00003S012 | [1] | O-RING | KOB |
| 32. | YZ10V00002S710 | [2] | O-RING | SM |
| 33. | YT10V00003S710 | [4] | O-RING | KOB |
| 34. | YX10V00003S015 | [12] | O-RING,1.9mm Thk x 8.8mm ID, 75 Duro | KOB |
| 35. | YT10V00003S708 | [4] | O-RING | KOB |
| 36. | YN10V01001S727 | [2] | O-RING | KOB |
| 37. | YM10V00006S733 | [2] | O-RING | SM |
| 38. | YX10V00003S011 | [1] | O-RING | KOB |
| 39. | YB10V00004S019 | [1] | OIL SEAL | KOB |
| 40. | ZD85P01400 | [2] | RING | KOBBack-Up -- ID 14 x OD 18 x Th 1.25mm |
| 41. | ZD85G03000 | [2] | BACK-UP RING | KOBID 30 x OD 35 x Th 1.25mm |
| 42. | ZN18C12007 | [2] | NUT | KOBM12x1.75mm |
| 43. | ZN18C16010 | [2] | NUT | KOBM16x2.0mm |
| 44. | ZR16X03500 | [2] | RING | KOBRetaining -- ID 32.20 x OD 35 x Th 1.6mm |
| 45. | ZP26D06014 | [4] | PIN | KOBRoll -- OD 06 x 14mm Long |
| 46. | ZS91C01000 | [2] | BOLT | KOBEye -- M10x1.50x18mm |
| 47. | YM10V00006S953 | [2] | SCREW | SM |
| 48. | 2437U188S954 | [2] | SCREW | KOB |
| 49. | YB15V00003S390 | [1] | PLATE | KOBPlate |
| 50. | 2437U407S983 | [2] | RIVET | KOB |
| K. | YM10V00006R100 | [1] | KIT | SMContains: 8x9, 9x9 Superseded by part number: YY10V00014R200 |
| K. | YM10V00006R200 | [1] | KIT | SMContains: 7, 24 |
| K. | YM10V00006R300 | [1] | KIT | SMContains: 7, 25 |
| K. | YM10V00006R400 | [1] | KIT | SMContains: 14, 15 |
| . . | YM10V00006R500 | [1] | KIT | SMContains: 32, 37 |
