神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (09-37[00]) - INJECTION EQUIPMENT - INJECTOR (101580510010) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
202 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2855399 | [4] | FUEL SYSTEM INJECTOR | TORIncludes Seal Pn 2856435 (15x7.3x0.5mm) Superseded by part number: 504125149 |
| 1. | 2855399R | [4] | REMAN-INJECT NOZZLE | RACREMAN-INJECTION NOZZLE Injector Nozzle Superseded by part number: 504125149R |
| 1. | 2855399C | [4] | CORE-NOZZLE, INJECT | RACReturn number |
| 2. | 4895297 | [4] | SEAL,7.3mm ID x 15mm OD x 2.5mm THK | TOR |
