| 1. | YB33H00017P1 | [1] | TANK, HYDRAULIC OIL | KOB Superseded by part number: 72230496 |
| 2. | ZD11G19000 | [1] | O-RING,189.30mm ID x 200.70mm OD x 5.70mm | KOBID 189.30 ± 1.47 x OD 200mm |
| 3. | ZD11G16500 | [1] | O-RING,164.30mm ID x 175.70mm OD x 5.70mm | KOBID 164.30 ± 1.30 x OD 175.7mm |
| 4. | YN33H01216P1 | [1] | COVER | KOB Superseded by part number: 72202074 |
| 5. | YM33H01007P1 | [1] | FLANGE | KOB Superseded by part number: 72203447 |
| 6. | ZE72X12000 | [1] | PLUG | KOB(3/4" PF) (Incls. O-Ring ZD12P02400) |
| . . | ZD12P02400 | [1] | O-RING | KOB(Part of ZE72X12000), ID 23.70 ± 0.24 x OD 30mm, Not Shown |
| 7. | ZS18C10025 | [10] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 8. | ZW16H10000 | [10] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 9. | YN58S00009F1 | [1] | GAUGE | KOBIncls. Refs. 10 - 15 |
| 10. | NA | [2] | NOT SERVICED | FORBlock |
| 11. | NA | [2] | NOT SERVICED | FORCapscrew M10x1.50x34mm |
| 12. | NA | [1] | NOT SERVICED | FORGauge |
| 13. | NA | [4] | NOT SERVICED | FORO-Ring |
| 14. | NA | [4] | NOT SERVICED | FORO-Ring |
| 15. | NA | [2] | NOT SERVICED | FORWasher |
| 16. | YW50V00004F7 | [1] | FILTER STRAINER | KOBIncls. Refs. 17 - 19 |
| 17. | YN50V00002S001 | [1] | STRAINER ASSY. | KOB |
| 18. | ZN11C10008 | [1] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 19. | YW50V00004S005 | [1] | BOLT | KOBM10x1.50x585mm |
| 20. | NA | [1] | NOT SERVICED | FORO-Ring |
| 21. | YN57V00002F4 | [1] | BREATHER ASSY. | KOBIncls. Refs. 22 - 29 Superseded by part number: YN57V00010F1 |
| 22. | NA | [1] | NOT SERVICED | FORBody Assembly |
| 23. | YN57V00002S010 | [1] | ELEMENT | KOBFilter See Figure 01-01 Superseded by part number: 47640920 |
| 24. | NA | [1] | NOT SERVICED | FORCover |
| 25. | NA | [1] | NOT SERVICED | FORSeal -- M12x Th 1.20mm |
| 26. | NA | [1] | NOT SERVICED | FORNut -- M12x1.25mm |
| 27. | 2446U260S10 | [1] | NUT | KOBM12x1.25mm |
| 28. | NA | [1] | NOT SERVICED | FORSeal |
| 29. | NA | [1] | NOT SERVICED | FORPacking |
| 30. | ZS28C06016 | [4] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm |
| 31. | ZW26K06000 | [4] | LOCK WASHER | KOBID 06 x OD 11 x Th 1.5mm |
| 32. | YN52V01008F4 | [1] | ELEMENT | KOBFilter, Incls. Refs. 33 - 38 Superseded by part number: YN52V01016F4 |
| 33. | YN52V01008S002 | [1] | PLATE | KOB |
| 34. | YN21V00015P1 | [1] | CHECK VALVE | KOB |
| 35. | ZD11G09000 | [1] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOBID 89.40 ± 0.77 x OD 95mm |
| 36. | YN52V01008S005 | [1] | PACKING | KOB |
| 37. | LC33H01009P1 | [1] | SPRING | KOB |
| 38. | YN52V01013P1 | [2] | HYDRAULIC OIL FILTER | KOBSee Figure 01-01 Superseded by part number: YN52V01021P1 |
| 39. | ZS13C16040 | [4] | SCREW | KOBM16x2.0x40mm |
| 40. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 41. | LE33H01017D1 | [3] | SHIM,1.0mm Thk | KOB(1.0) |
| K. | YN52V01008R200 | [1] | ELEMENT | KOBKit, Repair Contains Items 35, 36, 38(2) Superseded by part number: YN52V01016R210 |
| K. | YN52V01008R400 | [1] | REPAIR KIT | SMContains Items 33, 34, 35, 36, 38(2) Superseded by part number: YN52V01016R410 |
| K. | YN52V01008R800 | [1] | REPAIR KIT | KOBContains Items 2, 35, 36, 38(2) Superseded by part number: YN52V01016R810 |
