神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-55-02[00]) - GUARD INSTALLATION, (PATTERN CHANGER) (YM21C00019F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1021 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM21C01280F1 | [1] | GUARD | KOBGuard Assembly, Incls. Refs. 2 - 5 Superseded by part number: YN21C03244P2, YM21C01281P1, YN21C03767P1, LC21C01986P2 |
| 2. | NA | [1] | NOT SERVICED | FORGuard |
| 3. | YN21C03244P2 | [1] | FOAM INSULATION | KOB590x590mm |
| 4. | LC21C01986P2 | [1] | FOAM INSULATION | KOB740mm Long (29-1/8 in) |
| 5. | YN21C03767P1 | [1] | RUBBER BUSHING | KOB |
| 6. | YM21C01283P1 | [1] | PILLAR | KOBPillar |
| 7. | YB21C01267P1 | [1] | BRACKET | KOB |
| 8. | YM21C01255F1 | [1] | Guard Assembly, Incls. Refs. 9 - 11 Order Components | |
| 9. | YM21C01258P1 | [1] | COVER | KOB |
| 10. | YM21C01257P1 | [1] | FOAM INSULATION | KOB |
| 11. | YM21C01286P1 | [1] | FOAM INSULATION | KOB |
| 12. | ZS18C12025 | [21] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 13. | ZW16H12000 | [21] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 14. | YM21C01290P1 | [1] | COVER | KOBCover |
| 15. | YN21C03423P1 | [2] | CLAMP | KOBDouble -- Black Vinyl Covered |
| 16. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 17. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
