约翰迪尔零件查询RE160299 - AXLE Third Gear Clutch AssemblyEPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 342 次

Pos.	Part No	Qty	Parts name	Comments
1.	T173637	[7]	Disk With Outer Spline
2.	T173638	[7]	Disk With Inner Spline
3.	T172247	[AR]	Snap Ring	3.60 MM (.141")
3.	T172251	[AR]	Snap Ring	4.20 MM (.165")
3.	T181873	[AR]	Snap Ring	2.4 MM(.095")
3.	T181874	[AR]	Snap Ring	2.7 MM (.106")
3.	T181875	[AR]	Snap Ring	3.0 MM (.118")
3.	T181876	[AR]	Snap Ring	3.3 MM (.123")
4.	T294876	[1]	Solid Shim	SUB FOR T173639
5.	T173067	[1]	Snap Ring
6.	T173066	[2]	Snap Ring
7.	T173839	[7]	Disk Spring
8.	T173853	[1]	Piston
9.	T173958	[1]	O-Ring
10.	T173960	[1]	O-Ring
11.	T173852	[1]	Housing
12.	T172115	[2]	Piston Ring
13.	T294887	[1]	Shaft	SUB FOR T173858
14.	T171153	[1]	Stud
15.	T310105	[1]	Bearing	SUB FOR T173847 IMPORTANT: HIGH TOLERANCE BEARING REQUIRED IN IS LOCATION. USE ONLY JOHN DEERE PARTS SOURCED BEARINGS.
16.	T310104	[2]	Bearing	SUB FOR T173849 IMPORTANT: HIGH TOLERANCE BEARING REQUIRED IN IS LOCATION. USE ONLY JOHN DEERE PARTS SOURCED BEARINGS.
17.	T172104	[2]	Disk
18.	T172129	[2]	Thrust Bearing
19.	T172130	[2]	Thrust Washer
20.	T179594	[1]	Needle Bearing
21.	T173806	[1]	Idler
22.	T173636	[1]	Disk With Outer Spline
