约翰迪尔零件查询92 - BACKHOE CONTROL VALVE FOR OPEN-CENTER HYDRAULIC SYSTEM [A17]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 213 次

Pos.	Part No	Qty	Parts name	Comments
1.	U40972	[1]	Nut
2.	U40959	[1]	Screw
3.	A3190R	[2]	O-Ring	7/8" O.D. X 11/16" I.D.
4.	U40966	[1]	Spring
5.	U40960	[1]	Plunger
6.	R31136	[1]	Back-Up Ring	(SUB FOR U40963)
7.	R10093	[1]	O-Ring	7/16" O.D. X 5/16" J.D.
8.	AU40609	[1]	Seat
9.	AU40608	[1]	Pressure Relief Valve
10.	U40969	[1]	Washer
11.	U40973	[4]	Cap Screw
12.	15H561	[1]	Pipe Plug	HEX. CTSK., 1/2"
13.	AU40550	[1]	Port Plate
14.	U15973	[7]	O-Ring	(BETWEEN SECTIONS)
15A.	U40956	[3]	Resistor	(SUB AU40970)
15B.	AU40970	[3]	Check Valve
16.	AU40546	[3]	Housing	VALVE, STABILIZER AND BUCKET
17.	........	[4]	Washer	(SUB AU40970 OR AU40971)
18.	........	[3]	Restrictor	(SUB AU40970)
19.	U40951	[1]	Check Valve
20.	AU40548	[1]	Housing	VALVE, BOOM
21.	M4125T	[21]	O-Ring	(BETWEEN SECTIONS)
22.	AU40547	[1]	Housing	VALVE, SWING
23.	........	[1]	Restrictor	PLATE, (SUB AU40971)
24A.	U40957	[1]	Restrictor	CHECK, (SUB AU40971)
24B.	AU40971	[1]	Check Valve
25.	15H690	[1]	Pipe Plug	HEX. CTSK., 3/4"
26.	AU40551	[1]	Housing	VALVE, OUTLET
27.	AU40549	[1]	Housing	VALVE, CROWD
...	AU40614	[1]	Seal Kit	O-RING FOR BETWEEN SECTIONS
...	AU40438	[1]	Valve	CONTROL, SIX-SECTION, COMPLETE
