Pos.	Part No	Qty	Parts name	Comments
1.	U41161	[1]	Port Plate	L.H.
2.	........	[7]	O-Ring	1/16" X 1-3/8" O.D. (SUB FOR U15415, THIS APPLICATION) ( T68667 NO LONGER AVAILABLE)
3.	........	[14]	O-Ring	1/16" X 1-1/8 O.D. (SUB FOR U11326, THIS APPLICATION) ( T68666 NO LONGER AVAILABLE)
4.	U41164	[2]	Orifice	.0980")
5.	AU40749	[2]	Housing	STABILIZER VALVE, (SUB AU41882)
6.	AU40748	[1]	Housing	CROWD VALVE, (SUB AU41885)
7.	AU40747	[1]	Housing	BUCKET VALVE, (SUB AU41883)
8.	W11402	[1]	Orifice	.0785", (SUB FOR U41476)
9.	AU40750	[1]	Housing	SWING VALVE, (SUB AT34643)
10.	U41477	[1]	Orifice	.1130
11.	U41173	[5]	Cap Screw	5/16" X 12-3/4"
12.	12H303	[5]	Lock Washer	5/16"
13.	U41160	[1]	End Plate	R.H.
14.	U41166	[1]	Orifice	.1800"
15.	AU40755	[1]	Housing	BOOM VALVE, (SUB AT35260)
...	AU40972	[1]	O-Ring Kit	REPAIR SECTION ASSEMBLY
...	AT59144	[1]	Control Valve	REMANUFACTURED, (SUB FOR AU40676, AU41684 AND AU41880) (WHEN AT59144 IS INSTALLED ON BACKHOES WITH SERIAL NUMBERS 801 THRU 3300, ALSO ORDER (2) U42826 CONNECTOR LINKS AND (4) U42825 CONNECTOR LINKS)
